How to find the parts you need
① Click a link to view parts list below or download the spec sheet.
Frame AssemblyCylinder Assembly
Stroke & Speed Control
Ram Level Control
Front Operated, Parallel Adjusted Back Gage
Heavy Duty, Universal Gage Bracket & Gaging Stop
② Once you know which parts you want to order, request a parts quote.
Click to enlarge drawing
Frame Assembly
| 1 | Main Motor and Hydraulic Pump | 23 | Liner Mounting Bolt |
| 2 | Bolt | 24 | Ram Liner (R.H. & L.H.) |
| 3 | Valve Manifold | 25 | Pivot Shoe |
| 4 | Bolt | 26 | Pivot Block Retainer |
| 5 | Reservoir Cover | 27 | Retainer Mounting Bolt |
| 6 | Bolt | 28 | Pivot Block |
| 7 | L.H. Reservoir Cover Plate | 29 | Set Screw |
| 8 | Oil Level Gage | 30 | Adjusting Block |
| 9 | R.H. Reservoir Cover Plate | 31 | Bolt |
| 10 | Bolt | 32 | Crown Shield |
| 11 | Temperature Gage | 33 | Ram |
| 12 | Frame | 34 | Ram Clamp Bar |
| 13 | Ram Adjust Control | 35 | Clamp Mounting Bolt |
| 14 | Control Mounting Bolt | 36 | L.H. Gib |
| 15 | Actuator Bar | 37 | Washer |
| 16 | Electrical Control Box | 38 | Capscrew |
| 17 | Bolt | 39 | T-Nut |
| 18 | Ram Directional Control | 40 | Cylinder |
| 19 | Filler Block | 41 | Spring |
| 20 | R.H. Gib | 42 | Safety Rail |
| 21 | Bolt | 43 | Pillow Block |
| 22 | Gib Liner (R.H & L.H.) | 44 | Bolt |
Cylinder Assembly
| 1 | R.H. Cylinder | 41 | Capscrew |
| 2 | Pin | 42 | Angle |
| 3 | "O" Ring Seal | 43 | Key |
| 4 | Piston Rings | 44 | Motor |
| 5 | Capscrew | 45 | Capscrew |
| 6 | Piston | 46 | Capscrew |
| 7 | "O" Ring Seal | 47 | Stop Plate |
| 8 | Cylinder Cap | 48 | Ball Screw |
| 9 | Capscrew | 49 | Dowel |
| 10 | "V" Packing | 50 | Ball Seat |
| 11 | Wear Ring | 51 | Screw |
| 12 | Wiper Ring | 52 | Ball Screw Cap |
| 13 | Packing Gland | 53 | Plate |
| 14 | Capscrew | 54 | Capscrew |
| 15 | Ball Screw Nut | 55 | Bearing Cartridge |
| 16 | Worm Gear | 56 | Collar |
| 17 | Ram Adjusting Gear Box | 57 | Shaft |
| 18 | Retaining Ring | 58 | Bearing Cartridge |
| 19 | Spacer | 59 | Tape Idler |
| 20 | Bearing | 60 | Thrust Bearing |
| 21 | Spacer | 61 | Plate |
| 22 | Bushing | 62 | Nut |
| 23 | Pin | 63 | Capscrew |
| 24 | Worm Gear Shaft | 64 | Capscrew |
| 25 | Key | 65 | Gear Box |
| 26 | Key | 66 | Shaft |
| 27 | Motor Mount | 67 | Counter Gear |
| 28 | Capscrew | 68 | Intermediate Gear |
| 29 | Sprocket Hub | 69 | Counter Drive Gear |
| 30 | Set Screw | 70 | Screw |
| 31 | Sprocket | 71 | Gear Box Cover |
| 32 | Capscrew | 72 | Pin |
| 33 | Capscrew | 73 | Counter |
| 34 | Guard | 74 | Capscrew |
| 35 | Chain | 75 | Coupling |
| 36 | Capscrew | 76 | Pin |
| 37 | Sprocket | 77 | Set Screw |
| 38 | Set Screw | 78 | Shaft |
| 39 | Capscrew | 79 | Capscrew |
| 40 | Bar |
Stroke & Speed Control
| 1 | L.H. Cylinder | 35 | Set Screw |
| 2 | Pin | 36 | Key |
| 3 | "O" Ring | 37 | Capscrew |
| 4 | Piston Rings | 38 | Capscrew |
| 5 | Capscrew | 39 | Stop Plate |
| 6 | Piston | 40 | Ball Screw |
| 7 | "O" Ring | 41 | Dowel |
| 8 | Cylinder Cap | 42 | Ball Seat |
| 9 | Capscrew | 43 | Screw |
| 10 | "V" Packing | 44 | Ball Screw Cap |
| 11 | Wear Ring | 45 | Plate |
| 12 | Wiper Ring | 46 | Capscrew |
| 13 | Packing Gland | 47 | Plate |
| 14 | Capscrew | 48 | Capscrew |
| 15 | Ball Screw Nut | 49 | Nut |
| 16 | Worm Gear | 50 | Thrust Bearing |
| 17 | Ram Adjusting Gear Box | 51 | Tape Idler |
| 18 | Retaining Ring | 52 | Bearing |
| 19 | Spacer | 53 | Bearing Shaft |
| 20 | Bearing | 54 | Collar |
| 21 | Bearing Cartridge | 55 | Gear Box |
| 22 | Bushing | 56 | Counter Gear |
| 23 | Capscrew | 57 | Shaft |
| 24 | Set Screw | 58 | Intermediate Gear |
| 25 | Collar | 59 | Counter Drive Gear |
| 26 | Spring | 60 | Screw |
| 27 | Pin | 61 | Cover |
| 28 | Key | 62 | Roll Pin |
| 29 | Worm Gear Shaft | 63 | Counter |
| 30 | Coupling Sleeve | 64 | Screw |
| 31 | Bushing | 65 | Capscrew |
| 32 | Pin | 66 | Guard |
| 33 | Coupling Gear | 67 | Capscrew |
| 34 | Shaft |
Ram Level Control
| 1 | Block |
| 2 | Tape Idler |
| 3 | Tape Clamps |
| 4 | Cap Screws |
| 5 | Tape Holder |
| 6 | Nut |
| 7 | Cap Screw |
| 8 | Servo Valve |
| 9 | Rod |
| 10 | Spring |
| 11 | Washer |
| 12 | Screw |
| 13 | Tape |
| 14 | Bearing |
| 15 | Shaft |
| 16 | Collar |
| 17 | Valve Sub Plate |
| 18 | Cap Screw |
| 19 | Cap Screw |
| 20 | Plate |
| 21 | Bolt |
| 22 | Tape Adjusting Screw |
| 23 | Pin |
| 24 | Bracket |
| 25 | Cap Screw |
| 26 | Thrust Washer |
| 27 | Adjusting Nut |
| 28 | Tape Idler Assembly (R.H.) |
| 29 | Tape Idler Assembly (L.H.) |
| 30 | Set Screw |
Front Operated, Parallel Adjusted Back Gage
| 1 | Zee Frames |
| 2 | Cam |
| 3 | Cap Screw |
| 4 | Block Bearing |
| 5 | Cap Screws |
| 6 | Cam Anti-Backbend |
| 7 | Set Screw |
| 8 | Limit Switch (Speed) |
| 9 | Screw |
| 10 | Plate |
| 11 | Screw |
| 12 | Switch Mounting Block |
| 13 | Pin |
| 14 | Knob |
| 15 | Upper Cover Plate |
| 16 | Screw |
| 17 | Lower Cover Plate |
| 18 | Rod |
| 19 | Cam Mounting Block |
| 20 | Set Screw |
| 21 | Nut |
| 22 | Actuator Bar |
| 23 | Screw |
| 24 | Limit Switch (Strokes) |
| 25 | Limit Switch (Anti-Back Bend) |
Heavy Duty, Universal Gage Bracket & Gaging Stop
| 1 | Handle Screw | 25 | Sprocket |
| 2 | Hand Knob | 26 | Key |
| 3 | Hand Crank (Manually Driven) | 27 | Adjusting Screw |
| 3a | Spacer (Power Driven) | 28 | Guide Rod |
| 4 | Key | 29 | Set Screw |
| 5 | Helical Gear (Adjusting Screw) | 30 | Upright |
| 6 | Collar | 31 | Washer |
| 7 | Bushing | 32 | Cap Screw |
| 8 | Cover Screw | 33 | Upright Adjusting Screw |
| 9 | Counter Cover | 34 | Nut |
| 10 | Mounting Screw | 35 | Washer |
| 11 | Roll Pin (Used for Location) | 36 | Finger Rest |
| 12 | Counter Mounting Screw | 37 | Finger Bolt |
| 13 | Counter Bracket | 38 | Finger |
| 14 | Counter | 39 | Shoulder Bolt |
| 15 | Helical Gear (Counter) | 40 | Spring |
| 16 | Set Screw | 41 | Support Arm |
| 17 | Torque Tightening Sprocket | 42 | Collar |
| 18 | Mounting Bolt | 43 | Roll Pin |
| 19 | Chain | 44 | Roll Pin |
| 20 | Cartridge | 45 | Hand Crank |
| 21 | Bushing | 46 | Handle |
| 22 | Mounting Bolt | 47 | Stud |
| 23 | Collar | 48 | Knurled Knob |
| 24 | Set Screw |
Why use genuine Niagara parts?
① Good and Services Warranty
Purchase press parts with confidence from BCN Technical Services. We guarantee at the time of delivery, the goods will be free from defects in materials and workmanship. We will perform services in a prompt, professional and workmanlike manner. View our Goods and Services Warranty for details.
② Original OEM Specifications
Replacement parts are manufactured to original OEM specifications from record sets maintained by serial number, so there’s no guessing or wondering if a part will fit. We have original drawings, manufacturing expertise, and the experience of a team of engineers who know your press inside and out.
③ Delivery
BCN Technical Services has an extensive inventory of the most requested OEM replacement parts in stock at our facility in Hastings, MI. Over 14,000 unique spare parts for presses are kept on hand. Our experienced staff is dedicated to quickly providing that critical part, which allows you to avoid delayed repairs, lost productivity and lost revenue.
