IB 90 and Larger Hi-Lo
1. Scroll to view parts below or download a PDF Spec Sheet
2. Once you’ve found your part number and part name, request a parts quote
Questions? Contact Us
(Manual Number: B-13-D-2)
Click to enlarge
Download a PDF Spec Sheet
IB 90 and Larger Hi-Lo
| Part # | Part Name |
|---|---|
| 1 | Shaft |
| 2 | Bearing |
| 3 | Retaining Ring |
| 4 | Bearing |
| 5 | Retaining Ring |
| 6 | "O" Ring |
| 7 | Piston |
| 8 | Cylinder Back Plate |
| 9 | Spring |
| 10 | Screw |
| 11 | Cylinder |
| 12 | Washer |
| 13 | Spring |
| 14 | "O" Ring (lg.) |
| 15 | "O" Ring (sm.) |
| 16 | Brake Disc Assembly |
| 17 | Actuator |
| 18 | Flywheel |
| 19 | "O" Ring |
| 20 | Back Plate |
| 21 | Bearing |
| 22 | Hub |
| 23 | Clutch Disc Assembly |
| 24 | Screw |
| 25 | Washer |
| 26 | Spring |
| 27 | Screw |
| 28 | Shrink Disc (See Form A-36) |
